Conductor holder StSt f. Rd 8-10mm with cover plate and fixing material
Code: 274160Product detailed description
Conductor holder DEHNhold with a slotted saddle clamp, for fixing round conductors. For use with different materials, e.g. Al, StSt, St/tZn and Cu, fixed conductor routing, with female thread, pre-assembled with screw, plastic base and plug.Additional parameters
| Category: | Import |
|---|---|
| Weight: | 0.033 kg |
| EAN: | 4013364123380 |
| Assembly height conductor holder: | 30 |
| Držiak typového pripevnenia: | S príchytkou |
| Materiál držiaka: | Nehrdzavejúca oceľ (V2A) |
| Materiál spodnej časti: | Plastický |
| Spôsob upevnenia vodičov: | So závitovou príchytkou |
| Suitable for diameter round conductor: | 8-10 |
| Suitable for width flat conductor: | 20-20 |
| Thread size (metric): | 8 |
| Wall distance: | 30-30 |
